This Tesla meter is a portable and multifunctional magnetic field measuring instrument. Equipped with a high-sensitivity, low-drift Hall sensor and advanced digital signal processing, this meter is ideal for various applications such as:
- Measures surface magnetic field strength of permanent magnets, residual magnetism in mechanical parts, and magnetic separators.
- Suitable for magnetic material manufacturers, mechanical engineering companies, and university research labs.
Features:
- High-definition TFT screen with humanized UI interface
- Automatic and manual zeroing
- Low power consumption design (up to 16hrs battery life)
- Built-in rechargeable lithium battery
- Can store 50 groups of measured data
- High sensitivity and high precision hall sensors
- Measurement unit switching - mT or Gs
- Anti-slip design with back stand
- Sound & light alarm for over-limit value
- Self-calibration function
Specifications:
- Sensor: High-precision Hall sensor
- Magnetic field resolution: 0.01Gs / 0.01mT
- Measurement range: 0~25000 Gs / 0~2500 mT
- Measurement Accuracy: ±1%
- Two magnetic field units: mT, Gs, 1mT=10Gs
- Data Storage: Built-in storage of 50 groups of data.
- Battery life: ≈16 hours (continuous working mode)
- Operating temperature: -20~60°C (The maximum temperature of the external probe is 125℃)
- Power supply: Lithium battery with Type-C charging port
- Dimension: 140*63*27mm
- Weight: about 130g
Set Includes:
- 1 x Gauss Meter
- 1 x Hall Sensor Probe
- 1 x USB Type-C Cable
- English Instruction Manual
- Standard Factory Packaging
