The fiber optic identification instrument is a versatile, advanced tool used for non-destructive testing on both single-mode and multimode fibers. It features a built-in optical power module and a red light visual fault locator, essential for identifying faults and breaks in fiber links during construction and maintenance. This makes it a high-performance device that ensures efficient and reliable detection in modern fiber optic networks.
Features:
- Color screen display
- Metal structure 4-in-1 test fixture (can detect 250/900um and 2 to 3mm of various optical fibers)
- With online test to identify power direction, frequency detection function
- Low insertion loss, test dynamic range
- With ordinary power meter function (including frequency detection)
- With VFL function
- Low battery prompt
Specifications:
‒ Identifier module
- Wavelength range(nm): 800～1700
- Probe type: InGaAs
- Adapter type(mm): 250um, 900um, 2mm, 3mm
- Modulation frequency (Hz): CW, 270, 1K, 2K
- Optical fiber signal display detection range(dBm): 13～-50
- Signal direction detection range (dBm) Typical Value: 13～-35
- Signal frequency indication (Hz): 270, 1K, 2K
- Signal frequency detection range (dBm) Typical Value: 13～-30
‒ Standard OPM module
- Test wavelength (nm): 850, 1300, 1310, 1490, 1550, 1625
- Power test range (dBm): +26～-50
- Unit: dBm / dB / xW
- Resolution ratio (dB): 0.01
- Uncertainty (dB): ≤0.5
- Test interface: Φ2.5mm universal interface
‒ VFL module
- Wavelength (nm): 650±10
- Output power (mW): ≥10
- Test interface: Φ2.5mm universal interface
‒ Others
- Display screen: Color-LCD
- Power supply: 2 x 1.5V AA battery
- Operating temperature: -20～60℃
- Storage temperature: -30～70℃
- Dimension without switch pull button: 220 x 38 x 28 mm
- Weight: approx. 145gms
Set Includes:
- 1 x Optical Fiber Identifier
- 1 x Mini Screwdriver
- 1 x English Instruction Manual
- 2 x AA 1.5V Battery
- 1 x Carrying Bag
- Standard Factory Packaging
